Maintenance
HPR400XD Auto Gas – 806160 5-7
F5/N
2
process
Metering console
control board
Selection console control board
LED number 38 39 28 37 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Preflow B3 B1 SV6 SV9
Cutflow B4 B1 SV6 SV9 SV14
H35/N
2
process
Metering console
control board
Selection console control board
LED number 38 39 28 37 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Preflow B3 B1 SV5 SV9
Cutflow B4 B1 SV5 SV9 SV14
H35 & N
2
/N
2
process
Metering console
control board
Selection console control board
LED number 38 39 28 37 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Preflow B3 B1 SV5 SV9
Cutflow B4 B1 SV5 SV9 SV12 SV13
N
2
/Air
process
Metering console
control board
Selection console control board
LED number 38 39 28 37 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Preflow B3 B2 SV3 SV9 SV10
Cutflow B3 B2 SV3 SV9 SV10
Air/Air
process
Metering console
control board
Selection console control board
LED number 38 39 28 37 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Preflow B3 B2 SV2 SV3 SV8 SV10
Cutflow B3 B2 SV2 SV3 SV8 SV10
