Hypertherm HyPerformance HPR400XD Auto Gas User Manual

Parts List
6-22 HPR400XD Auto Gas – 806160
Recommended spare parts
Power supply
Part
Number Description Designator Qty.
129633 Green power lamp assembly 1
129792 Chopper assembly CH1, CH2, CH3, CH4 1
127039 6” fan: 230 CFM, 115 VAC 50-60 HZ 1
027079 10” fan: 450-550 CFM, 120 VAC 50-60 HZ 1
003149 Relay: Pilot arc, 120 VAC CR1 1
229213 PCB: I/O 1
003232* Contactor CON1 1
003228** Contactor CON1 1
109004 Current sensor: Hall 100 amp, 4 volt CS1, CS2, CS3, CS4 1
229238 Start circuit assembly PCB1 1
008551 Fuse: 7.5 amp, 600 volt F1, F2 2
141030 PCB: Control PCB3 1
041802 PCB: Power distribution PCB2 1
108028 Fuse: 3 amp, 250 volt F5, F6, F7 3
108075 Fuse: 6.3 amp, 250 volt (slow-blow) F1, F2, F3 3
108709 Fuse: 10 amp, 250 volt F4 1
228171 Kit: Pump with clamp 1
228230 Kit: Motor with clamp 1
141027 PCB: Pump motor drive PCB7 1
* 200/208, 220 and 240 volt power supplies
** 380, 400, 440, 480 and 600 volt power supplies
Cooler
Part
Number Description Designator Qty.
041897 PCB: Console power distribution 1
008756 Fuse: 5 amp, 250 volt (slow-blow) F1 1
027634 Filter housing (on the rear panel of the cooler) 1
027664 Filter element 1
027926 Filter housing (under the coolant tank) 1
229235 Flow sensor FS1 1
006113 Check valve: 3/8” FPT 1
229229 Solenoid valve 1
141033 PCB: Cooler sensor 1
Ignition console
Part
Number Description Designator Qty.
041817 HFHV Ignition PCB 1
129854 Transformer T1 1
