Parts List
HPR400XD Auto Gas – 806160 6-23
Selection and metering consoles
Part
Number Description Designator Qty.
228069 Kit: Control PCB PCB2 1
041897 Power distribution PCB PCB1 1
008756 Fuse: 5 amp, 250 volt (slow-blow) F1 1
041822 Valve driver PCB PCB3 1
008756 Fuse: 5 amp, 250 volt (slow-blow) F1 1
228984 Solenoid valve SV3 and SV10 2
006109 Solenoid valve SV1, SV2, SV4-SV9, SV11-SV15 13
005263 Pressure sensor 1
011109 Air filter housing (on the rear panel of the selection console) 1
011110 Air filter element 1
