Hypertherm HyPerformance HPR400XD Auto Gas

Wiring Diagrams
HPR400XD Auto Gas – 806160 7-3
Switch, Level, Normally Closed
Time Delay Closed, NO/Off Transformer
Electrode
Torch Symbols
Nozzle Shield Torch
Transformer, Air Core Transformer Coil Valve, Solenoid Voltage Source Zener Diode VAC Source Triac
Switch, Pressure, Normally Closed Switch, Pressure, Normally Open Switch, 1 Pole, 1 Throw Switch, 1 Pole, 2 Throw Switch, 1 Pole, 1 Throw, Center Off Switch, Temperature, Normally Closed Switch, Temperature, Normally Open Time Delay Closed, NC/Off Time Delay Open, NO/Off
Time Delay Open, NC/On
Terminal Block
Torch, HyDefinition™
Switch, Flow
