Page #334 background imageLoading...
Page #334 background image
Appendix B – CnC interfACe protoCol
HPR400XD Auto Gas806160 b-15
Command table (10 of 14)
ID Command System Description
114 READ_INPUTS Manual gas system
Auto gas system
This command will return the status of inputs to the PC board.
Data:
None
Return value:
1 = on, 0 = off
Power Supply
Serial program
Plasma start
Hold ignition
Phase OK
Arc detect
Pierce complete
Corner current
Redundant start
Serial ID0
Serial ID1
Serial ID2
Dipswitch #1
Dipswitch #5
Dipswitch #6
Dipswitch #7
Dipswitch #8
Chopper A overcurrent
Chopper B overcurrent
Sample:
>11496<
>114000000000000000000F6<
117 READ_GAS_INPUTS_FROM_PS Manual gas system
Auto gas system
This command will allow the CNC to query the gas console I/O
by sending the command to the serial port on the power supply
control board.
Data:
None
Return value:
1 = on, 0 = off
Manual Gas Console
Error select
Status select
Test preflow
Test cutflow
Serial ID bit 0
Serial ID bit 1
Serial ID bit 2
Auto Gas Console
Metering dipswitch 2
Metering dipswitch 3
Metering dipswitch 4
Select dipswitch 1
Select dipswitch 2
Select dipswitch 3
Select dipswitch 4
Metering dipswitch 1
Sample:
>11799<
>1170000000E9<
