Appendix B – CnC interfACe protoCol
b-22 HPR400XD Auto Gas – 806160
ID Name Description
054 HIGH SHIELD GAS PRESSURE Gas pressure is over upper limit of 7.58 bar (110 psi).
055 MV 1 INLET PRESSURE
Motor valve 1 inlet pressure is less than 3.45 bar (50 psi) or
greater than 9.65 bar (140 psi).
056 MV 2 INLET PRESSURE
Motor valve 2 inlet pressure is less than 3.45 bar (50 psi) or
greater than 9.65 bar (140 psi).
057 CUT GAS 1 PRESSURE
In the selection console, cut gas 1 outlet pressure is less than
3.45 bar (50 psi) or greater than 9.65 bar (140 psi).
058 CUT GAS 2 PRESSURE
In the selection console, if cut gas 2 outlet pressure is less than
3.45 bar (50 psi) for non-mixing, or less than 1.38 bar (20 psi)
when mixing or greater than 9.65 bar (140 psi) for non-mixing
andmixing.
060 LOW COOLANT FLOW Coolant flow is less than the required 2.3 lpm (0.6 gpm).
061 NO PLASMA GAS TYPE Plasma gas has not been selected.
062 NO SHIELD GAS TYPE Shield gas has not been selected, or system is in test mode.
065 Primary
265 Secondary
CHOPPER1 OVERTEMP Chopper #1 overheated.
066 Primary
266 Secondary
CHOPPER2 OVERTEMP Chopper #2 overheated.
067 Primary
267 Secondary
MAGNETICS OVERTEMP Transformer has overheated.
071 COOLANT OVERTEMP Torch coolant has overheated.
072
AUTOMATIC GAS CONTROL
BOARD OVERTEMP
Control board has exceeded 90° C (194° F).
073 Primary
273 Secondary
CHOPPER3 OVERTEMP Chopper #3 overheated
074 Primary
274 Secondary
CHOPPER4 OVERTEMP Chopper #4 overheated
075 Primary
275 Secondary
CURRENT TOO LOW ON LEM
#3
A current less than 10 amps has been detected by current
sensor 3.
076 Primary
276 Secondary
CURRENT TOO LOW ON LEM
#4
A current less than 10 amps has been detected by current
sensor 4.
093 NO COOLANT FLOW Coolant flow is less than 0.6 gpm.
095
CURRENT TOO HIGH ON LEM
#4
Current has exceeded 35 amps during the chopper test
099 Primary
299 Secondary
CHOPPER1 OVERTEMP AT INIT Chopper #1 is indicating overtemp during power-up.
100 Primary
300 Secondary
CHOPPER2 OVERTEMP AT INIT Chopper #2 is indicating overtemp during power-up.
101 Primary
301 Secondary
MAGNETICS OVERTEMP AT
INIT
Transformer is indicating overtemp during power-up.
102 Primary
302 Secondary
OUTPUT CURRENT AT INIT Chopper current signal is active on power-up.
103 Primary
303 Secondary
CURRENT TOO HIGH ON LEM
#1
A current greater than 35 amps has been detected by current
sensor 1.
104 Primary
304 Secondary
CURRENT TOO HIGH ON LEM
#2
A current greater than 35 amps has been detected by current
sensor 2.
105 Primary
305 Secondary
CURRENT TOO LOW ON LEM
#1
A current less than 10 amps has been detected by current
sensor 1.
