SPECIFICATIONS
2-4 powermax30 Operator Manual
Torch dimensions
8.72" ( 221 mm)
8.5" (216 mm)
3.10"
(79 mm)
1.58"
(40 mm)
1.00"
(25 mm)
T30v torch ratings
2.00" (50 mm)
Recommended capacity 1/4 inch (6 mm) at 30 A (35% duty cycle)
Maximum capacity 3/8 inch (10 mm) at 30 A (35% duty cycle)
Severance capacity 1/2 inch (12 mm) at 30 A (35% duty cycle)
Weight 2.1 lbs (1.0 kg)
