Parts
powermax 65/85 Operator Manual 6-13
Machine torch consumables
Part number Description
Shielded
220817 Shield 45/65/85 A
220854 Retaining cap 45/65/85/105 A
220953 Ohmic retaining cap 45/65/85/105 A
220941 45 A Nozzle
220819 65 A Nozzle
220816 85 A Nozzle
220842 Electrode 45/65/85/105 A
220857 Swirl ring 65/85 A
Unshielded
220955 Deflector 65/85/105 A
220854 Retaining cap 45/65/85/105 A
220941 45 A Nozzle
220819 65 A Nozzle
220816 85 A Nozzle
220842 Electrode 45/65/85/105 A
220857 Swirl ring 65/85 A
Gouging
220798 Gouging shield 65/85/105 A
220854 Retaining cap 45/65/85/105 A
220797 Gouging nozzle 65/85 A
220842 Electrode 45/65/85/105 A
220857 Swirl ring 65/85 A
FineCut
1
220955 Deflector 65/85/105 A
220948 FineCut shield
220854 Retaining cap 45/65/85/105 A
220953 Ohmic retaining cap 45/65/85/105 A
220930 FineCut Nozzle
220842 Electrode 45/65/85/105 A
220857 Swirl ring 65/85 A
1
The deflector (220955) is used only with the standard retaining cap (220854). The shield (220948) is used only with
the ohmic retaining cap (220953).
