Hypertherm powermax85

Torch SeTup
3-42 powermax 65/85 Operator Manual
Low Speed FineCut Air flow rate – slpm/scfh
Stainless Steel
Hot 155 / 330
Cold 215 / 460
Metric
Material
Thickness
Current
Torch-
to-Work
Distance
Initial Pierce Height
Pierce Delay
Time
Recommended
Cut Speed Voltage
mm A mm mm % seconds (mm/min) Volts
0.5
30
0.5 2.0 400
0.0
3800 69
0.6 3800 69
0.8 0.1 3800 69
1
40
0.15 3800 69
1.5
0.4
2900 69
2 2750 69
3
45
0.5 2550 80
4 0.6 1050 80
English
Material
Thickness
Current
Torch-
to-Work
Distance
Initial Pierce Height
Pierce Delay
Time
Recommended
Cut Speed Voltage
A in in % seconds ipm Volts
26GA
30
0.02 0.08 400
0.0
150 69
24GA 150 69
22GA
0.1
150 69
20GA 150 69
18GA
40
0.2 145 69
16GA
0.4
115 69
14GA 110 69
12GA
45
0.5 120 80
10GA 0.6 75 80
