Troubleshoot Common Problems
6
128 810470 Operator Manual Powermax65/85/105 SYNC
The plasma arc goes out
but ignites when you pull
the torch trigger again.
• Decrease the length of the arc stretch. Whenever possible, drag the torch
on the workpiece. Refer to page 99.
• Examine the Hypertherm cartridge. Replace it if it is worn or damaged. A
higher rate of 0-30-0 faults is typical as a cartridge gets near end-of-life.
Refer to Signs that a cartridge is near end-of-life on page 108 and
Cartridge maintenance on page 170.
• Make sure that the incoming gas supply hose has an internal diameter of
9.5 mm (3/8 inch) or greater.
• Examine the gas filtration system for contamination that is possibly
interfering with plasma power supply performance. Refer to page 126.
• If you manually adjusted the gas pressure before this problem occurred, set
the gas pressure back to the default setting. Refer to page 77.
The torch does not cut
completely through the
workpiece.
• Examine the Hypertherm cartridge. Replace it if it is worn or damaged. A
higher rate of 0-30-0 faults is typical as a cartridge gets near end-of-life.
Refer to Signs that a cartridge is near end-of-life on page 108 and
Cartridge maintenance on page 170.
• Decrease your cut speed.
• Make sure that the operating mode is correct for the Hypertherm cartridge
that you are using. Refer to page 77.
• Restart the plasma power supply. Does it correctly recognize
the type of Hypertherm cartridge installed? Does it correctly set
the amperage and operating mode for the Hypertherm
cartridge? If it does not, look at the LCD screen. Do you see the
non-default configuration icon (at right)? If yes, there is possibly
a system configuration setting that you must change. Refer to page 151. If
no, there is possibly a problem with the Hypertherm cartridge, torch, or
plasma power supply. Speak to your distributor or authorized repair facility.
• Make sure that the torch is being used correctly. Refer to Cut with the Hand
Torch on page 95.
• Increase the output current (A) on the plasma power supply. Refer to
page 72.
• If the output current (A) cannot be increased, make sure that the thickness
of the metal being cut is less than the maximum capacity for this plasma
power supply. Refer to Cutting specifications on page 35.
• Clean the area where the work clamp touches the workpiece. Remove any
rust, paint, or other material. Make sure that there is good metal-to-metal
contact.
• Examine the torch lead. Make it straight if it is twisted or kinked. Replace it if
it is damaged.
• Examine the gas pressure and the gas supply hose. Refer to page 125.
• Adjust the gas flow rate. Refer to Gas supply source on page 55.
When I try to adjust the
output current (A) using
the button on the
SmartSYNC hand torch,
the amperage setting on
the plasma power supply
does not change.
• Is the system in basic mode? The amperage-adjustment control
on the hand torch cannot be used when the system is in basic
mode. Refer to Smart mode versus basic mode on page 151. If
the
status screen shows the non-default configuration icon (at
right), set the plasma power supply to factory default settings to
go back to smart mode. Push and hold and at the same time
for approximately 2 seconds.
