HySecurity SlideDriver 50VF2/3 User Manual

Specifications
FAST FAST
1,500 lb (680 kg) gates
1 ft/s (30 cm/s)
3,000 lb (1,361 kg) gates
1.7 ft/s (50 cm/s)
4,000 lb (1,814 kg) gates
1 ft/s (30 cm/s)
5,000 lb (2,268 kg) gates
2.2 ft/s (70 cm/s) or
3 ft/s (91 cm/s)
8,000 lb (3,629 kg) gates
1 ft/s (30 cm/s)
20,000 lb (9,072 kg) gates
1 ft/s (30 cm/s)
Model SlideDriver 15 SlideDriver 30F SlideDriver 40 SlideDriver 50VF2/3 SlideDriver 80 SlideDriver 200
Part # 222 SS ST 222 EX 1.7 ST 222 E ST 222 X3 ST 222 X1 ST 444 XS ST
Duty Cycle Continuous
Horsepower 1 hp 2 hp 1 hp 2 hp 2 hp 5 hp
Drive Hydraulic
Drive Wheels
Two 6” (15 cm) AdvanceDrive
wheels
Two 6” (15 cm)
AdvanceDrive wheels
Two 6” (15 cm)
AdvanceDrive wheels
Two 8” (20 cm)
AdvanceDrive wheels
One 8” (20 cm) AdvanceDrive
wheel, One 8” XtremeDrive
wheel and 27 ft (8 m) of rack
Two 8” (20 cm) Advance-
Drive wheels, Two 8”
XtremeDrive wheels and 52
ft (16 m) of rack
Gate Weight Max. 1,500 lb (680 kg) 3,000 lb (1,361 kg) 4,000 lb (1,814 kg) 5,000 lb (2,268 kg) 8,000 lb (3,629 kg) 20,000 lb (9,072 kg)
Gate Length Max. Limited only by weight
Drawbar Pull 300 lb (136 kg) 300 lb (136 kg) 300 lb (136 kg) 300 lb (136 kg) 600 lb (272 kg) 1,200 lb (544 kg)
Rate of Travel 1 ft/s (30 cm/s) 1.7 ft/s (50 cm/s) 1 ft/s (30 cm/s)
Field adjustable, 2.2 ft/s
(70 cm/s) or 3 ft/s (91 cm/s)
Emergency Fast Close
3 ft/s (91 cm/s)
1 ft/s (30 cm/s) 1 ft/s (30 cm/s)
Temperature Rating -40º F to 158º F (-40º C to 70º C) No heater necessary
1 Phase Power
115/208/230V 60 Hz
110/220V 50 Hz
208/230V 60 Hz
220V 50 Hz
115/208/230V 60 Hz
110/220V 50 Hz
208/230V 60 Hz
220V 50 Hz
208/230V 60 Hz
220V 50 Hz
230V 60 Hz
220V 50 Hz
3 Phase Power 208/230/460V or 575V 60Hz; 220/380/440V 50Hz
208/230V 60/50Hz
or 380/460V 60/50Hz
208/230/460V or 575V 60Hz; 220/380/440V 50Hz
Communication RS-232, RS-485, Ethernet/ber using optional HyNet™ Gateway accessory
User Controls
Smart Touch Controller with 70+ congurable settings. Smart Touch keypad and display or a PC using S.T.A.R.T. soware.
Relays
ree congurable user relays: one 30VDC, 3A solid state and two 250VAC, 10A electromechanical; Optional Hy8Relay™ for 8 additional relay outputs
Finish Zinc plated with powder coating
Listed to UL325 Usage Class I, II, III, IV Usage Class III, IV Usage Class I, II, III, IV Usage Class III, IV Usage Class III, IV Usage Class III, IV
Warranty 5 year
UPS Backup Power Options and Additonal Models
DC Power Supply* SlideDriver 15 UPS SlideDriver 30F UPS SlideDriver 40 UPS – SlideDriver 80 UPS SlideDriver 200 UPS**
AC Power Supply
with HyInverter*
SlideDriver 15
with HyInverter
–
SlideDriver 40
with HyInverter
SlideDriver 50VF2/3
with HyInverter
– –
Correctional Facility – SlideDriver 30F-C SlideDriver 40-C SlideDriver 50VF2/3-C SlideDriver 80-C SlideDriver 200-C
Modular SlideDriver 15-M SlideDriver 30F-M SlideDriver 40-M SlideDriver 50VF2/3-M SlideDriver 80-M SlideDriver 200-M
* 3,000 ft/hr expected duty cycle. ** 2,000 ft/hr expected duty cycle. Actual duty cycle depends on site specic conditions and gate conguration.
To enable fully automatic operation, this gate operator requires a MINIMUM of one external entrapment protection sensor to monitor potential entrapment zones
in either the open or close direction of travel. Visit www.hysecurity.com/gatesafety for more information on UL 325 standards and gate safety
Copyright Notice
© Copyright 2019 by HySecurity Gate, Inc.
All rights reserved. No part of this manual may be reproduced by any means (photocopier, electronic, or
mechanical), without the express written permission of HySecurity Gate, Inc. Federal copyright law prohibits the
reproduction, distribution, or public display of copyrighted materials without the express written permission of
the copyright owner, unless fair use or other exemption under copyright law applies. Additionally, HySecurity
Gate, Inc. makes no representations or warranty with respect to this manual. We also reserve the right to make
changes in the products described without notice and without any obligation to notify any persons of any such
revision or change.
Trademarks
SlideDriver, StrongArm, SwingRiser, StrongArm CRASH, StongArm M30, StrongArm M50, HydraLift, HydraSwing,
HydraWedge SM50, HydraSupply XL, HydraSupply, HyNet, Hy8Relay, HyInverter AC, HyCharger DC, SlideWinder,
Smart Touch, S.T.A.R.T., SwingSmart DC, SlideSmart DC, StrongArmPark DC, WedgeSmart DC, Smart DC and the
HySecurity logo are trademarks or registered trademarks of HySecurity Gate, Inc.
UL and UL logo are trademarks of UL LLC and ETL is a trademark of Intertek.
Intertek provides the ETL Listed Mark.
Products called out in Wiring HySecurity Sensors are trademarks or registered trademarks of Miller Edge, Inc., OMRON Corporation, and
Encon Electronics.
www.hysecurity.com © 2019 MX3630-01 Rev. J 145
