5
Before Use
Attaching the Battery
To remove the battery, turn off the radio first.
1
2
3
7
8
9
10
4
5
6
“click”
Attaching the Earpiece Attaching the Belt
1
2
“click”
2
1
3
Caution
Attaching the Earpiece
1. Open the connector cover as ① shown.
2. Align the index of the earpiece with that of the radio and connect the
earpiece to the radio as ② shown.
3. Turn the earpiece clockwise as ③ shown to fasten it.
Attaching the Belt Clip
After the belt clip is assembled to the radio, you can wear the radio to a
certain xture (such as a belt).
To attach the belt clip, do as follows:
To Next Page
