Hytera PD415 - Page 122

UHF1 (400
‐
470 MHz)
Parts List
56
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
456
D1005
B1H
3304010100220
Varactor
954
RN103
B4K
3005051010010
100Ω
457
D1006
B3H
3303030800020
Switching diode
955
RN104
B3I
3005051010010
100Ω
458
D1007
B1I
3304010100890
Varactor
956
RN105
B5J
3005051010010
100Ω
459
D1008
B3G
3399030000010
PIN diode
957
RN106
B5J
3005051010010
100Ω
460
D1009
B1I
3304010100220
Varactor
958
RT801
T2E
3003994730000
Thermistor
461 D101 B3I 3301990000030
Schottky barrier
diode
959 SW102 B1C 4318080000000
Momentary
contact switch
462 D1010 B1I 3304010100220 Varactor 960 SW103 B1E 4318080000000
Momentary
contact switch
463 D1011 B1I 3304010100220 Varactor 961 SW104 B1F 4318080000000
Momentary
contact switch
464
D1012
B1I
3304010100220
Varactor
962
T601
B4F
5406000000200
Transformer
465 D102 T1B 3399040600000
ESD protection
diode
963 T602 B4F 5406000000200 Transformer
466 D103 T1B 3399040600000
ESD protection
diode
964 U101 B4J 3609017000130 MCU
467 D104 T2B 3399040600000
ESD protection
diode
965 U102 B2J 3612051000020 Memory
468 D105 T1B 3399040600000
ESD protection
diode
966 U103 B4I 3609006000000 Reset IC
469 D106 T1C 3399040600000
ESD protection
diode
967 U105 T3K 3805003560000 EMI filter
470 D107 T1E 3399040600000
ESD protection
diode
968 U106 T3K 3805003560000 EMI filter
471
D108
T2B
3307110100070
LED (super red)
969
U107
T4K
3805003560000
EMI filter
