Hytera PD415 - Page 123

Parts List
UHF1 (400
‐
470 MHz)
57
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
472 D109 T3B 3307110100080
LED (super
green)
970 U201 B2K 3613999000150
Baseband
processor IC
473 D110 T1F 3399040600000
ESD protection
diode
971 U202 T3J 3606010000070 D/A conversion IC
474 D301 T3E 3399040600000
ESD protection
diode
972 U203 T3J 3617023000000 Logic IC
475
D302
T2F
3302030000030
Zener diode
973
U204
B1K
3617023000000
Logic IC
476 D303 T4B 3399040600020
ESD protection
diode
974 U301 T5H 3608025000010
Power
management IC
477 D304 T4B 3399040600000
ESD protection
diode
975 U302 T2G 3608015000270
Power
management IC
478 D306 T4H 3303030100010 Switching diode 976 U303 T1F 3608015000270
Power
management IC
479 D401 T4C 3399040600020
ESD protection
diode
977 U304 T3I 3608006000000
Power
management IC
480 D402 T1C 3399040600020
ESD protection
diode
978 U305 T1K 3608006000000
Power
management IC
481 D403 T4C 3310249900000
ESD protection
diode
979 U306 B4D 3608006000000
Power
management IC
482 D404 T4C 3399040600020
ESD protection
diode
980 U307 T2K 3608006000000
Power
management IC
483 D405 T5D 3303030800020 Switching diode 981 U310 T1H 3608006000000
Power
management IC
484 D406 T5D 3303030800020 Switching diode 982 U311 T5J 3608025000010
Power
management IC
485 D407 T3E 3303030300000
Schottky barrier
diode
983 U401 T3C 3605017005540
Operational
amplifier
486 D408 T4E 3399040600000
ESD protection
diode
984 U402 T4E 3605008005070
Operational
amplifier
487 D409 T4E 3399040600000
ESD protection
diode
985 U501 T3H 3603018000000 IF processor IC
488 D410 T4D 3310249900000
ESD protection
diode
986 U601 T3G 3616010000000 Switch IC
489 D411 T4D 3310249900000
ESD protection
diode
987 U701 T2G 3605025000020
Operational
amplifier
490
D601
B2D
3304010100220
Varactor
988
U901
T2J
3604019000000
PLL IC
491 D602 B3C 3303030300000
Schottky barrier
diode
989 U902 T2I 3616059000000 Switch IC
492
D603
B3D
3304010100220
Varactor
990
U903
T1H
3616010000000
Switch IC
493
D605
B3E
3304010100220
Varactor
991
X101
B4I
3701001260120
Crystal
494
D606
B4E
3304010100220
Varactor
992
X201
T3J
3701122830020
TCXO
495
D607
B4F
3301250300000
Schottky diode
993
X901
T1J
3701019250000
VC-TCXO
496
D701
T2F
3303030800020
Switching diode
994
Z501
B4H
3801045030170
Ceramic filter
497 D801 B2C 3303030800040 Switching diode 995 Z502 B4G 3920450300020
Frequency
discriminator
498
D803
B2C
3399030000010
PIN diode
996
Z601
T4F
3802580540010
Crystal filter
