Hytera PD415 - Page 56

Parts List
VHF1 (136
‐
174 MHz)
49
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
54
C1050
B1I
3101050200010
2pF
568
L309
T2K
3221506181000
Ferrite bead
55
C1051
B2I
3101011020060
1000pF
569
L310
B5D
3221506181000
Ferrite bead
56
C1052
B1I
3101054700010
47pF
570
L311
T2K
3221506181000
Ferrite bead
57
C1053
B1I
3101061000000
10pF
571
L314
T2H
3221506181000
Ferrite bead
58
C1054
B1I
3101060800010
8pF
572
L315
T4I
3221505121010
Ferrite bead
59
C1055
B1I
3101051510000
150pF
573
L316
T5J
3217099153000
15uH
60
C1056
B1I
3101051020010
1000pF
574
L401
T3B
3210107332000
3.3uH
61
C1059
B1I
3101053900000
39pF
575
L402
T3E
3221506601000
Ferrite bead
62
C1060
B2I
3101053000010
30pF
576
L403
T4E
3221505121010
Ferrite bead
63
C1061
B2I
3101051010030
100pF
577
L404
T4E
3221505121010
Ferrite bead
64
C1062
B2I
3101011100000
11pF
578
L405
T4E
3221505121010
Ferrite bead
65
C1063
B2I
3101012290010
2.2pF
579
L406
T4E
3221505121010
Ferrite bead
66
C1064
B3G
3101051200020
12pF
580
L407
T4D
3221505121010
Ferrite bead
67
C1065
B3H
3101051500020
15pF
581
L409
T4E
3221505121010
Ferrite bead
68
C1066
B3G
3101051200020
12pF
582
L503
T3H
3210306561010
560nH
69
C1067
B2I
3101010400000
4.0pF
583
L504
T3H
3210306561010
560nH
70
C1068
B2I
3101011500020
15pF
584
L601
B3C
3221505121010
Ferrite bead
71
C1069
B2I
3101010400000
4.0pF
585
L602
T3F
3221505121010
Ferrite bead
72
C107
T2B
3101054710010
470pF
586
L603
B3D
3210306101000
100nH
73
C1072
B3H
3101055610040
560pF
587
L604
B3D
3212106121000
120nH
74
C1074
B3G
3101014710020
470pF
588
L605
B3E
3237199270000
Air-core coil 27nH
75
C1075
B3G
3101014710020
470pF
589
L606
B4E
3210106220000
22nH
76
C1077
B2I
3101010400000
4.0pF
590
L607
B4E
3237199270000
Air-core coil 27nH
77
C1078
B2I
3101011040100
0.1uF
591
L608
T3F
3221505121010
Ferrite bead
78
C1079
B2J
3101012290010
2.2pF
592
L609
B3D
3217106781000
780nH
79
C108
T2C
3101054710010
470pF
593
L610
B2D
3237199270000
Air-core coil 27nH
80
C1080
B2I
3101011020060
1000pF
594
L611
B3D
3237199270000
Air-core coil 27nH
81
C1081
B2I
3101011040100
0.1uF
595
L612
B3C
3210106680000
68nH
82
C109
T2C
3101054710010
470pF
596
L613
B2D
3210106560000
56nH
83
C110
T1B
3101054710010
470pF
597
L614
T3G
3213306222000
2.2uH
84
C111
B3I
3101051000020
10pF
598
L615
T3G
3001060000000
0Ω
85
C112
B4I
3101051000020
10pF
599
L616
T4G
3213306681010
0.68uH
86
C113
T1C
3101054710010
470pF
600
L617
B4F
3213306681010
0.68uH
87
C114
T1D
3101054710010
470pF
601
L618
T3G
3210406331000
330nH
88
C115
B4I
3101011040100
0.1uF
602
L620
B5F
3210306221000
220nH
89
C116
B5I
3101052240010
0.22uF
603
L621
B3G
3210106220000
22nH
90
C117
B5I
3101011040100
0.1uF
604
L622
B3G
3212106330000
33nH
91
C118
B3K
3101011040100
0.1uF
605
L7909
B1D
3239999130000
Air-core coil 13nH
92 C119 B4I 3101011040100 0.1uF 606 L7910 B1D 3233099190020
Air-core coil
18.5nH
93 C120 B5K 3101011040100 0.1uF 607 L7911 B1C 3233099190020
Air-core coil
18.5nH
94
C121
B5I
3101011040100
0.1uF
608
L801
B1G
3221506601000
Ferrite bead
95
C122
B3I
3101011040100
0.1uF
609
L802
B2E
3221506181000
Ferrite bead
96
C123
B4I
3101011040100
0.1uF
610
L803
B3E
3233099470000
Air-core coil 47nH
97
C124
B3K
3101014710020
470pF
611
L804
B2F
3217112102020
1uH
98
C125
B3I
3101014710020
470pF
612
L805
B1B
3217107221020
220nH
99
C126
B5I
3101062250000
2.2uF
613
L808
B2C
3233099470000
Air-core coil 47nH
100
C127
B4I
3101011030050
0.01uF
614
L809
B3C
3233099470000
Air-core coil 47nH
101
C128
B4I
3101014710020
470pF
615
L810
B3C
3233099470000
Air-core coil 47nH
102
C129
T2B
3101011040100
0.1uF
616
L811
B1F
3212106829000
8.2nH
103
C130
T3B
3101011040100
0.1uF
617
L813
B2C
3233099470000
Air-core coil 47nH
104
C131
T1F
3101054710010
470pF
618
L816
B1G
3221506601000
Ferrite bead
105
C132
T2B
3101014710020
470pF
619
L817
B1G
3212105470000
47nH
106
C133
T2B
3101014710020
470pF
620
L819
B2G
3001050000020
0Ω
107
C134
B4K
3101011010030
100pF
621
L901
T2I
3221505121010
Ferrite bead
108
C136
T4K
3101051040060
0.1uF
622
L902
T2I
3221505121010
Ferrite bead
109
C137
T4K
3101051050160
1uF
623
L903
T2I
3221505121010
Ferrite bead
110
C138
B4I
3101011030050
0.01uF
624
L904
T1I
3221505121010
Ferrite bead
111
C202
T3J
3101011040100
0.1uF
625
L905
T1J
3221505121010
Ferrite bead
112
C203
T3J
3101071060280
10uF
626
L906
T1J
3221505121010
Ferrite bead
