Hytera PD415 - Page 57

VHF1 (136
‐
174 MHz)
Parts List
50
No. Ref No.
Print
No.
Part No. Description No. Ref No.
Print
No.
Part No. Description
113
C206
T3J
3101071060280
10uF
627
L907
T1J
3210306561010
560nH
114
C208
T3I
3101051040060
0.1uF
628
L909
T2I
3221505121010
Ferrite bead
115
C209
T3J
3101011030050
0.01uF
629
Q1001
B2H
3408002000080
NPN transistor
116 C210 T3I 3101054730000 0.047uF 630 Q1002 B2H 3403999000070
Compound
transistor
117
C211
T3I
3101071060280
10uF
631
Q1003
B2H
3403003000060
NPN transistor
118 C212 T3J 3101051040060 0.1uF 632 Q1004 B2I 3403999000070
Compound
transistor
119 C214 T3J 3101051040060 0.1uF 633 Q1005 B2H 3403999000070
Compound
transistor
120
C215
T3J
3101013300010
33pF
634
Q1006
B3H
3408002000000
NPN transistor
121
C216
T3J
3101013300010
33pF
635
Q1007
B3H
3401002000990
NPN transistor
122
C217
T3J
3101013300010
33pF
636
Q101
B3K
3503010000010
P-MOSFET
123
C218
T3J
3101013300010
33pF
637
Q1010
B1I
3408002000080
NPN transistor
124 C219 T4I 3101071060280 10uF 638 Q1011 B3H 3403999000070
Compound
transistor
125 C220 T3J 3101051040060 0.1uF 639 Q103 T2B 3503040000000
Compound
MOSFET
126
C221
T4J
3101051040060
0.1uF
640
Q301
T2F
3505990000040
P-MOSFET
127
C222
T4J
3101051040060
0.1uF
641
Q304
T4G
3599990000610
N-MOSFET
128
C223
T4J
3101011040100
0.1uF
642
Q401
T2C
3505990000040
P-MOSFET
129
C224
B2J
3101011040100
0.1uF
643
Q402
T4D
3505990000040
P-MOSFET
130 C226 T3J 3001051020000 1KΩ 644 Q403 T3G 3403008000010
Bias resistor
transistor
131
C227
T3J
3101011040100
0.1uF
645
Q404
T4D
3599990000610
N-MOSFET
132
C228
T3J
3101011040100
0.1uF
646
Q405
T4D
3401001000490
PNP transistor
133
C231
T3J
3101011040100
0.1uF
647
Q406
T4C
3599990000610
N-MOSFET
134
C232
T3J
3101011040100
0.1uF
648
Q502
T3H
3401002000990
NPN transistor
135 C233 T4J 3101011040100 0.1uF 649 Q504 T4G 3403007000020
Bias resistor
transistor
136 C235 T3I 3101014710020 470pF 650 Q601 B3C 3403999000070
Compound
transistor
137
C236
T3I
3101011040100
0.1uF
651
Q602
B3D
3418001000010
NPN transistor
138
C237
B1K
3101011040100
0.1uF
652
Q604
T3G
3401002000990
NPN transistor
139 C238 T2K 3101011040100 0.1uF 653 Q701 T1G 3403014000020
Compound
transistor
140 C239 B2K 3101014710020 470pF 654 Q702 T2G 3403008000010
Bias resistor
transistor
141 C240 T2K 3101011040100 0.1uF 655 Q703 T2G 3403999000070
Compound
transistor
142 C241 T2K 3101014710020 470pF 656 Q801 B1G 3403999000070
Compound
transistor
143
C242
T2K
3101011040100
0.1uF
657
Q802
B1F
3504990000010
PA MOSFET
144
C243
B2K
3101014710020
470pF
658
Q803
B1E
3504990000070
N-MOSFET
145
C244
T2K
3101011040100
0.1uF
659
Q804
B1G
3420999000060
NPN transistor
146 C245 T2K 3101014710020 470pF 660 Q901 T2H 3403999000070
Compound
transistor
147
C246
T2K
3101011040100
0.1uF
661
R1001
B1H
3001053320010
3.3KΩ
148
C247
T2K
3101014710020
470pF
662
R1002
B2H
3001014720050
4.7KΩ
149
C248
T2K
3101011040100
0.1uF
663
R1003
B2H
3001018230000
82KΩ
150
C249
T2K
3101014710020
470pF
664
R1004
B2I
3001011020060
1KΩ
151
C250
T2K
3101011040100
0.1uF
665
R1005
B1H
3001058220010
8.2KΩ
152
C251
B2K
3101011040100
0.1uF
666
R1006
B2H
3001011010080
100Ω
153
C252
B2J
3101014710020
470pF
667
R1007
B2I
3001018230000
82KΩ
154
C253
B2K
3101011040100
0.1uF
668
R1008
B2I
3001011020060
1KΩ
155
C254
B2J
3101014710020
470pF
669
R1009
B2H
3001018230000
82KΩ
156
C255
T2K
3101011040100
0.1uF
670
R101
B3K
3001011010080
100Ω
157
C256
B2J
3101014710020
470pF
671
R1010
B2I
3001014730010
47KΩ
158
C257
B2K
3101011040100
0.1uF
672
R1011
B2H
3001062210000
220Ω
159
C258
B2K
3101014710020
470pF
673
R1012
B3H
3001051020000
1KΩ
160
C259
B2J
3101011040100
0.1uF
674
R1013
B3H
3001051810010
180Ω
