3.3.2 Factory-set Parameters (Default Settings)
Settings
No. Parameter name Input range
A B C
Remarks
1
Input/output port assignment type
0 ~ 20 0 0 0
0: Fixed assignment
1: Automatic assignment (Priority: Slot 1
~)
* Ports are assigned automatically only
for the contiguous slots in use, starting
from slot 1 = For safety reasons.
2
Standard I/O fixed assignment:
Initial input port number (I/O1)
-1 ~ 599 000 000 -1
0 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
3
Standard I/O fixed assignment:
Initial output port number (I/O1)
-1 ~ 599 300 300 -1
300 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
4
Expansion I/O1 fixed assignment:
Initial input port number (I/O2) -1 ~ 599 -1 -1 -1
0 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
(Slot next to standard I/O)
5
Expansion I/O1 fixed assignment:
Initial output port number (I/O2)
-1 ~ 599 -1 -1 -1
300 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
6
Expansion I/O2 fixed assignment:
Initial input port number (I/O3)
-1 ~ 599 -1 -1 000
0 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
7
Expansion I/O2 fixed assignment:
Initial output port number (I/O3)
-1 ~ 599 -1 -1 300
300 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
8
Expansion I/O3 fixed assignment:
Initial input port number (I/O4)
-1 ~ 599 -1 -1 -1
0 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
9
Expansion I/O3 fixed assignment:
Initial output port number (I/O4)
-1 ~ 599 -1 -1 -1
300 + (multiple of 8) (The parameter is
invalid if a negative value is set.)
10
Standard I/O error monitor
0 ~ 5 2 2 2 0: Not monitored
11
Expansion I/O1 error monitor
0 ~ 5 0 0 0 1: Monitored
12
Expansion I/O2 error monitor
0 ~ 5 0 0 2
2: Monitored (24-V I/O power errors are
not monitored)
(Main application version 0.55 or
later)
13
Expansion I/O3 error monitor
0 ~ 5 0 0 0
3: Monitored (only 24-V I/O power
errors are not monitored).
(Main application version 0.55 or
later)
14
Network I/F card remote input
ports used
0 ~ 256 64 64 64
Multiple of 8
15
Network I/F card remote output
ports used
0 ~ 256 64 64 64
Multiple of 8
