24
4. Connecting to a RCS-C, E-Con or Scon
4.1 Models
External views (front views) of the RCS, E-Con and Scon controllers that support ProfiBus-DP are shown
below.
(1) RCS-C
Models:
I/O points: Eight dedicated input points, 10 dedicated output points
RCS-C 24-V type
RCS-C 100/200-V type
