3.3.6 X-SEL I/O Port Numbers
The standard I/O port numbers of the X-SEL are listed below.
The port numbers and function assignments of the X-SEL can be changed using I/O parameters.
(For details, refer to “Operation Manual for X-SEL Controller.”)
Port No. Function Port No. Function
000 Program start 300 Alarm output
001 General-purpose input 301 Ready output
002 General-purpose input 302 Emergency stop output
003 General-purpose input 303 General-purpose output
004 General-purpose input 304 General-purpose output
005 General-purpose input 305 General-purpose output
006 General-purpose input 306 General-purpose output
007 Program specification (PRG No. 1) 307 General-purpose output
008 Program specification (PRG No. 2) 308 General-purpose output
009 Program specification (PRG No. 4) 309 General-purpose output
010 Program specification (PRG No. 8) 310 General-purpose output
011 Program specification (PRG No. 10) 311 General-purpose output
012 Program specification (PRG No. 20) 312 General-purpose output
013 Program specification (PRG No. 40) 313 General-purpose output
014 General-purpose input 314 General-purpose output
015 General-purpose input 315 General-purpose output
Input
Output
Note) The above functions are based on the factory-set default parameter settings.
