Manual ibaCom-L2B-x-8
8 Issue 3.2
 Each slave may send and receive data simultaneously (same telegram mode for
both directions)
 LEDs for each PROFIBUS-line for CPU active (green), PROFIBUS-line o.k. (yel-
low), internal error (red)
 7-segment display for board id and synchronization status
 Baud rates up to 12 Mbaud
 Automatic baud rate detection
 Profibus termination resistors for each PROFIBUS-line (switch)
 100% compatibility to its predecessors on the PROFIBUS side (GSD data)
3 Scope of delivery
After unpacking check the completeness and intactness of the delivery.
The scope of delivery includes:
 Device ibaCom-L2B-x-8
 Manual
 Synchronization cable preassembled
 GSD files
4 System requirements
4.1 Hardware
IBM-compatible PC with the following minimum configuration:
 400 MHz Pentium II or better
 128 MB RAM or better
 At least one free PCI slot with 5V cable (V2.2, 5 V, 32/64 bit)
Please see http://www.iba-ag.com for further details on a properly outfitted workstation.
4.2 Software
 Microsoft Windows NT4.0 (SP 6), 2000, XP, 2003, Win 7
 PDA Version 4.07 with PCI support or higher or
 ibaLogic V3.65 or higher
