12 Technical data
12.1 Main data ibaFOB-D/ibaFOB-Dexp
Short description
Designation ibaFOB-D/ibaFOB-Dexp
Description
PCI and PCI Express boards with FO connectors for ibaNet con-
nections
Name Order no. Name Order no. FO connectors
ibaFOB-4i-D 11.115700 ibaFOB-4i-Dexp 11.118000 4 x Input
ibaFOB-2i-D 11.115710 ibaFOB-2i-Dexp 11.118030 2 x Input
ibaFOB-2io-D 11.115800 ibaFOB-2io-Dexp 11.118010 2 x Input
2 x Output
ibaFOB-io-D 11.115810 ibaFOB-io-Dexp 11.118020 1 x Input
1 x Output
Connectors
FO cable 62,5/125 µm
FO connector ST Lean
Distance between 2 devices Max. 1.24 mi (2000 m), without repeater
ibaNet protocols 2Mbit, 3Mbit, 5Mbit, 32Mbit, 32Mbit Flex
Supplies and indications
Power supply
3.3 V or 5.0 V over PCI bus;
or 12 V over PCIe 1.0-x1 compatible slot
Bus clock 33 MHz or 66 MHz / 2.5 Gbit/s (PCIe)
Power consumption Typ. 4.2 W
Indicators 4 LED per FO connector (state of communication)
7 Segment indication
Environmental conditions
Cooling Passive
Mounting
PCI slot for 32 bit or 64 bit or
PCIe 1.0-x1 compatible slot (x1, x4, x8, x16)
Operating temperature 32 °F to 122 °F (0 °C to 50 °C)
Storage temperature -13 °F to 158 °F (-25 °C to 70 °C)
Transport temperature -13 °F to 158 °F (-25 °C to 70 °C)
Assembly dimension (d x h)
PCI board 32 Bit
PCI Express board HW version A
PCI Express board HW version B
6.69 in x 3.82 in (170 mm x 97 mm)
6.69 in x 3.98 in (170 mm x 101 mm)
5.20 in x 3.98 in (132 mm x 101 mm)
Weight
(incl. box and documentation)
Approx. 0.44 lb (200 g)
Standards FCC part 15 class A
