12.2 Main data Extension module
Short description
Designation ibaFOB-4o-D
Description
Extension module for ibaFOB-D for mirroring of FO
inputs or for active FO outputs
Name Order no. FO connectors
ibaFOB-4o-D rackline slot
(short design for ibaRackline)
11.116200 4 x Outputs
ibaFOB-4o-D-PCI
(long design for PCI slot)
11.116201 4 x Outputs
Connectors
FO cable 62,5/125 µm
FO connector ST Lean
Distance between 2 devices Max. 1.24 mi (2000 m), without repeater
ibaNet protocols 2Mbit, 3Mbit, 5Mbit, 32Mbit, 32Mbit Flex
Indications 1 LED for connectors status
Environmental conditions
Cooling Passive
Mounting PCI slot for 32 bit or 64 bit
Operating temperature 32 °F to 122 °F (0 °C to 50 °C)
Storage temperature -13 °F to 158 °F (-25 °C to 70 °C)
Transport temperature -13 °F to 158 °F (-25 °C to 70 °C)
Assembly dimension (d x h) 1.46 in x 2.95 in (37 mm x 75 mm)
Weight (incl. box and documentation) Approx. 0.33 lb (150 g)
Standards FCC part 15 class A
