BIOS SETUP
IB891 User’s Manual 25
Onboard Serial Port
The default values are:
Serial Port 1: 3F8/IRQ4
Serial Port 2: 2F8/IRQ3
Serial Port 3: 3E8/IRQ11
Serial Port 4: 2E8/IRQ10
Restore on AC Power Loss
This field sets the system power status whether Power On or Power Off when
power returns to the system from a power failure situation.
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration
Options
Disabled
70°C/158°F
75°C/167°F
80°C/176°F
85°C/185°F
90°C/194°F
95°C/203°F
<- Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
System Temperature :51°C/123°F
CPU Temperature :47°C/116°F
CPU FAN Speed :0 RPM
Vcore :0.968 V
+5VS
+3VS
:5.338 V
:3.200 V
12 V :11.904 V
3.3V :3.424 V
1.5V :1.504V
VBAT : 3.536V
ACPI Shutdown Temperature [Disabled]
The Hardware Health Configuration menu is used to show the operating
temperature, fan speeds and system voltages.
ACPI Shutdown Temperature
The system will shut down automatically under OS with ACPI mode, when the
CPU temperature reaches the configured temperature.
