SC N450 / 512K cache/1.66 GHz (5.5W)
Intel® Atom
TM
DC D510 / 1MB cache/1.66GHz (14.5W)
22mm x 22mm, Micro-FCBGA8
Green /APM
APM1.2
BIOS
AMI BIOS, support ACPI Function
Chipset
ICH8M: 31mm x 31mm, 676-pin T-PBGA (2.4W)
Memory
DDR2 667MHz
SO-DIMM x 1 (w/o ECC), Max. 2GB
4GB , Single channel
VGA
Intel® Integrated Graphics Controller
Supports DirectX 9 Graphic (200MHz/ 400MHz), OpenGL 1.4
LVDS
18-bit one channels LVDS interface w/DF13 socket x1
LAN
Realtek 8111DL x 2
USB
ICH8M built-in USB 2.0 host controller, support 8 ports
Serial ATA Ports
ICH8M built-in SATA controller, supports 2 ports
Parallel IDE
ICH8M built-in one channel Ultra DMA 33/66/100, for CF Type II
Audio
Intel ICH8M built-in audio controller w/ Realtek ALC662 Codec
(supports 5.1 CH audio & SSM2304 2W/4ohm Amplifier
LPC I/O
Winbond W83627UHG :
COM1 (RS232/422/485), COM2(RS232)
COM3(RS232) & COM4(RS232) with pin-9 with power for 2 ports
(500 mA for each port)
Hardware monitor (2 thermal inputs, 4 voltage monitor inputs,
VID0-4 & 1 x Fan Header)
Digital IO
4 in & 4 out
Keyboard/Mouse
Connector
Pin header
Expansion Slots
Mini PCI-e socket x 1 for Wireless LAN or TV-tuner module
Edge Connector
DB15 x1 for VGA
RJ45 x2 for LAN 1&2
USB stack connector x 1 for USB1 ~2
DB9 x 1 for COM1
On Board
Header/Connector
2x5 pin header for KB/MS
2x4 pins header x 3 for 6 USB ports
DF13 socket connector x 1 for 18-bit single channel LVDS
2x6 pins box header x1 for Audio
4 pins header x1 for speaker
2x5 pins box header x 1 for COM2
2x10 pins box header x 1 for COM3 ~4
2x5 pins headers x 1 for LPC( 80-port card debugging purpose)
Mini PCI-e(1x) connector x 1
Compact Flash socket x 1
5 pins box header x 1 for smart battery
4 pins box header x 1 for backlight/brightness control
4-pins power connector for SATA HDD
Watchdog Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
Power Connector
+12V DC-in
RoHS
Yes
Board Size
102mm x 147mm
