IBASE Technology IB891 - Page 40

BIOS SETUP
36 IB891 User’s Manual
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
South Bridge Chipset Configuration
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
<- Select Screen
↑↓ Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
USB Function [8 USB Ports]
USB 2.0 Controller [Enabled]
HAD Controller [Enabled]
SMBUS Controller [Enabled]
PCIE Ports Configuration
PCIE Port 0 [Auto]
PCIE Port 1 [Auto]
PCIE Port 2 [Auto]
PCIE Port 3 [Auto]
PCIE Port 4 [Auto]
PCIE Port 5 [Disabled]
PCIE High Priority Port [Disabled]
PCIE Port 0 IOxAPIC Enable [Disabled]
PCIE Port 1 IOxAPIC Enable [Disabled]
PCIE Port 2 IOxAPIC Enable [Disabled]
PCIE Port 3 IOxAPIC Enable [Disabled]
PCIE Port 4 IOxAPIC Enable [Disabled]
PCIE Port 5 IOxAPIC Enable [Disabled]
Enable Onboard PCI option ROM [Disabled]
USB Function
This option enables the number of USB ports desired or disables the USB
function
.
USB 2.0 Controller
This option is disabled by default.
HDA Controller
This option is used to enable the Southbridge high definition audio controller.
SMBUS Controller
This option is enabled by default.
Enable Onboard PCI option ROM
This option is disabled by default.
