Specifications
The specifications of the UPS and the extended battery module are shown in the
following tables.
Note: All dimensions include the front bezel.
Table 1. 11000 VA LCD 5U rack UPS specifications
Specification 11000 VA LCD 5U rack UPS (200 V / 208 V / 230 V)
Height 212 mm (8.3 in.)
Width 483 mm (19 in.)
Depth 740 mm (29.1 in.)
Weight (including the internal batteries) 99 kg (218 lb)
Operating temperature at 0 to maximum altitude 0°C to 40°C (32°F to 104°F)
24 hour transport storage temperature at 0 to
maximum storage altitude
-15°C to 60°C (5°F to 140°F)
Extended storage temperature at 0 to maximum
storage altitude
-15°C to 45°C (5°F to 113°F)
Maximum operating altitude 3048 m (10,000 ft)
Maximum storage altitude 15,240 m (50,000 ft)
Relative humidity 0 to 95% noncondensing
Nominal input voltage 200 V / 208 V / 230 V (auto sensing at first power-up)
Maximum RMS current (in normal mode, battery
fully charged)
59.3 amps (200 V)
59.0 amps (208 V)
58.4 amps (230 V)
Input voltage range for main operations (V ac) 184 to 276 V ac
Nominal output voltage (V ac) 200 V / 208 V / 230 V (auto sensing at first power-up; user
configurable)
Input frequency 50/60 Hz±3Hz(auto sensing)
Rated power output 11000 VA (Normal and High Efficiency modes)
5500 VA (Converter mode)
Output power capacity in watts 10000 W (Normal and High Efficiency modes)
5000 W (Converter mode)
Circuit breakers Four two-pole output breakers rated at 20 A (two each for
Load Segment 1 and Load Segment 2)
Fixed power cord Hard-wired
Input connection type Terminal block
Power outlets Eight IEC 320 - C19
Audible noise at 1 meter for > 80% load <55 dBA normal / Bypass mode
<55 dBA Battery mode
Runtime (for fully charged internal batteries at 25°C) Full load (10 kW): 4.25 min
9kW:5min
8 kW: 6.5 min
7kW:8min
Half load (5 kW): 14 min
4 11000 VA UPS and 11000 VA EBM: Installation and Maintenance Guide
