Chapter 2. Installing the uninterruptible power supply
This chapter shows the front and rear views of the uninterruptible power supply
(UPS) and extended battery module and includes information about the following
topics:
v Checking the package contents
v Connecting the extended battery module to the UPS
v Installing a remote emergency power-off connector
v Hard-wiring the UPS input (for licensed electrician only)
v UPS initial startup
You will need the following tools to install the UPS:
v One number 2 Phillips screwdriver (for use with the rack mount kit and terminal
block cover)
v One flat-blade screwdriver (for wiring the terminal block)
Inventory checklist
The UPS comes with the following items.
Note: Your UPS model might not come with all of the items in the following list.
v UPS
v Two bezels (upper and lower)
v Rack mount kit, including rails and mounting hardware
v Documentation package
v IBM UPS Manager CD (power-management software)
v Serial and USB communication cables
v Remote emergency power-off connector
v Shipping bracket (provides extra protection for the UPS when shipped in a rack
cabinet)
© Copyright IBM Corp. 2011 7
