IBM 11000 VA LCD 5U - UPS and Extended Battery Module Views

Front view of the UPS
The following illustration shows the front view of the UPS.
OK
100%
6
min
1
5
0
0
VA
208
V
/60hz
UPS ON
For more information about the control panel on the front of the UPS, see “Control
panel” on page 27.
