Chapter 5. Hardware maintenance information
This chapter contains information about IBM customer replaceable units (CRUs)
and field replaceable units (FRUs) for the uninterruptible power supply (UPS) and
instructions for replacement parts that are not installed during a typical installation.
Replaceable UPS components
The replaceable components in the UPS are Tier 1 customer replaceable units
(CRUs). Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1
CRU at your request, you will be charged for the installation.
For information about the terms of the warranty and getting service and assistance,
see Appendix A, “Getting help and technical assistance,” on page 63 and the
Warranty Information document that comes with the product.
Important: Next-day delivery of the batteries might not be possible in all locations
because of transportation and logistics.
Table 12. 11000 VA UPS CRU listing
Description MTM or part number CRU part number (Tier 1)
UPS chassis
11000 VA (208 V / 230 V)
5395-9KX 81Y2321
Battery module (This CRU part contains the two
battery modules that are required for the UPS.)
5395-9KX 81Y2323
Bezel, upper (11000 VA UPS) 5395-9KX 69Y6095
Bezel, lower (11000 VA UPS) 5395-9KX 81Y2325
USB cable 69Y6073
RS-232 cable 69Y6074
Rack mount kit 69Y6094
Remote emergency power-on (REPO) switch 69Y6075
Environmental monitoring probe kit 41Y9210
Network management card 46M4112
Network management card setup cable (serial
communication cable)
81Y2372
Table 13. 11000 VA extended battery module CRU listing
Description MTM or part number CRU part number (Tier 1)
Extended battery module (11000 VA) 69Y1986 81Y2330
Bezel, 3U extended battery module 81Y2325
UPS and battery care
For the best preventive maintenance, keep the area around the UPS clean and
dust-free. If the atmosphere is very dusty, clean the outside of the system with a
vacuum cleaner. For full battery life, keep the UPS at an ambient temperature of
25°C (77°F).
© Copyright IBM Corp. 2011 47
