106
Adapter Cards
Installing Adapter Cards
q
Remove the screw that secures the adapter card
retainer and slot cover. Then remove the card retainer
and slot cover.
q
Align and insert the adapter card into the adapter card
connector.
q
Secure the card with the screw that you removed in the
first step.
q
Reinstall all hardware (except for the slot cover, which
cannot be reinstalled) and screws that you removed prior
to the installation of the adapter card.
