Introduction
This chapter gives a general overview of the machine types
2193, 2194, 2196, 2197, 6344 and 6345, describes the
standard and optional features, and details functional and
environmental specifications. Machine types 2196, 2197 and
6344 are desktop models. Machine types 2193, 2194 and
6345 are micro tower models.
Product Overview
All the machine type mentioned above contain three PCI
slots, and the system board supports the AMD K6-2
processor and Intel Pentium III processors.
Listed below are system features:
Processors (Machine Types 2193 and 2196)
• Processor with the capabilities of 3D Now™! technology
• Socket-7 Zero Insertion Force (ZIF) connector. You must
remove the old processor to install an upgrade processor.
• Detachable CPU heat sink with fan.
• One of the following processors can be installed:
− AMD K6-2 500 MHz CPU with 3D Now™! technology
− AMD K6-2 533 MHz CPU with 3D Now™! technology
− AMD K6-2 550 MHz CPU with 3D Now™! technology
Processors (Machine Types 2194, 2197, 6344 and 6345)
• Socket 370
• Detachable CPU heat sink with fan.
• One of the following processors:
− Intel Celeron 500 MHz CPU
− Intel Celeron 533 MHz CPU
− Intel Celeron 600 MHz CPU
− Intel Pentium III 550 MHz CPU
− Intel Pentium III 600 MHz CPU
