Introduction
This chapter contains system board layouts and jumper
settings. It is useful when you are asked to measure voltages.
Use this information to help you locate parts such as
electronic boards, connectors, pin numbers, and test points.
This chapter also contains jumper settings for the hard disk
drive, CD-ROM (compact disc-read-only memory) drive, and
the connector information for modem adapter card.
