137
Power Supply Cable Connector Specifications
Refer to the following figures when checking for voltages on
power supply cable connectors.
When checking voltages, the power supply fan must be
running. To power on the power supply without using the
on/off switch, use a screwdriver or other tools to short the
power supply connector (with the switch cable disconnected
from the connector on the system board) or use a connection
(jumper) to short the black and green wires of the 20-pin
connector on power supply.
10
20
1
11
Figure 5-3 System Board Power Supply Connectors
