121
Diskette Drive
To remove the diskette drive:
q
Disconnect the power and signal cables from the back of
the diskette drive.
q
Pull up the latch that secures the drive mounting tray.
q
Slide the drive mounting tray toward the front of the
computer and remove it.
q
Remove the four screws (two on each side) that secure
the bay holder.
q
Pull the diskette drive from the mounting tray to remove
it.
q
Reverse the procedure to install a new drive.
