136
Connectors and Functions of the System Board of
Machine Types 2193 and 2196
Table 5-4
Connector Function
BAT 1 Battery socket
J1 ATX Power connector
J2 CPU FAN Connector
J4 Hard Disk connector (Primary IDE)
J5 CD-ROM Drive connector (Secondary IDE)
J7 USB and LAN connector
J9 DIMM 0
J10 DIMM 1
J11 PCI Slot 1
J12 PCI Slot 2
J13 PCI Slot 3
J14 Floppy Diskette connector
J15 Power Switch
J16 Printer, COM 1 and VGA connector
J17 PS/2 Key Board and Mouse connector
J18 Power and HDD LED connector
J19 CD Audio in connector
J20 Game port, Audio In, Audio Out and MIC
connector
J21 Passive speaker connector
