108
Diskette Drive
To remove the diskette drive :
q
Disconnect the power and signal cables from the back of
the diskette drive.
q
Pivot the latch that secures the lower drive mounting
tray.
q
Slide the drive mounting tray toward the rear of the
computer and remove it.
q
Remove the four screws (two on each side) that hold the
diskette drive to the mounting tray.
