Appendix
C.
Mounting
surface
templates
Use
the
template
in
Figure
C-1
as
a
guide
for
mounting
the
distributed
pedestal
assembly.
35 mm
(1.37 in.)
20 mm
(.80 in.)
62 mm
(2.44 in.)
8 mm (5/16 in.)
diameter
22 mm (7/8 in.)
diameter
Figure
C-1.
Distributed
pedestal
mounting
template
©
Copyright
IBM
Corp.
1999,
2003
C-1
