Use
the
template
in
Figure
C-2
as
a
guide
for
mounting
the
free-standing
pedestal.
Mounting
dimensions—Models
10D,
1FR
Figure
C-3
on
page
C-3
is
provided
for
mounting
Models
10D
and
1FR.
19.6 mm
(0.77 in.)
Diameter=12 mm (0.47 in.)
Diameter=7.2 mm (0.28 in.)
Front
Back
Diameter=7.2 mm (0.28 in.)
75.3 mm
(2.96 in.)
Figure
C-2.
Free-standing
pedestal
mounting
template
C-2
4820
SurePoint
Solution
System
Reference
