Chapter 3. Installation and operating information
This section summarizes the installation and operation methods of the 4820 SurePoint
Solution. IBM recommends that you refer to the IBM 4820 SurePoint Solution
Installation and Service Guide for complete instructions.
Option installation
IBM recommends that you install the options for the 4820 SurePoint Solution in the
following order:
1. MSR
2. Keypad (Model 42T only)
3. Pointing device (Model 42T only)
Cable connections and routing
Table 3-1 summarizes the cable connections for the 4820 SurePoint Solution.
Table 3-1. Cable types and icons
Type Identifying Icon Cable
Analog
Power
.
