configuring MPI
6 Multi–Platform Interface Feature Operation Guide
SW1-2 SW1-1 EMULATION SELECTED
=>> 0 0 4214
0 1 5225
1 0 5256
1 1 4234
SW1-4 SW1-3 DEFAULT CHARACTER SET
=>> 0 0 MULTINATIONAL
0 1 USA
1 0 AUSTRIA/GERMANY
1 1 FRENCH CANADIAN
SW1-6 SW1-5 IGP OPTIONS
=>> 0 0 NO IGP INSTALLED
0 1 IGP-PGL INSTALLED*
1 0 IGP-VGL INSTALLED**
1 1 RESERVED
SW1-7 PRINTER TYPE
=>> 0 6400-PRINTRONIX
1 6400-EPSON
SW1-8 PRINTER EMULATION (6400-PRINTRONIX)
=>> 0 P-SERIES COMPATIBLE
1 SERIAL MATRIX
SW2-1 DEFAULT IGP SFCC
=>> 0 ^ CARET (5Eh, 94d)
1 ~ TILDE (7Eh, 126d)
SW2-3 SW2-2 PANEL AND SYSTEM CONTROL
=>> 0 0 SYSTEM CONTROLS CPI AND PRINT QUALITY
0 1 SYSTEM CONTROLS CPI, PANEL CONTROLS PRINT QUALITY
1 0 PANEL CONTROLS CPI, SYSTEM CONTROLS PRINT QUALITY
1 1 PANEL CONTROLS CPI, PRINT QUALITY, AND LPI
SW2-4 MULTIPLEXER TIMEOUT
=>> 0 SHORT (15 SEC)
1 LONG (45 SEC)
Table 1 Sample Configuration Printout (Twinax)
note
If you are replacing an existing Printronix P-
Series printer, SW1-7 and SW1-8 should be
set to the Open (Off) state. This will provide
compatibility with existing jobs. Also, if you
will be port switching, you should set SW1-7
and SW1-8 to be compatible with the
alternate host. See page 12 for more
information. If you set SW1-7 to 6400
Printronix (Open), you must set SW1-8. If
you set SW1-7 to 6400-Epson (Closed), you
do not need to set SW1-8 and you can
leave SW1-8 to the factory default.
note
* indicates IGP Feature installed.
** indicates Code V Feature installed.
