diagnostics
50 Multi–Platform Interface Feature Operation Guide
ADDRESS
SELECTION
DIAGNOSTIC TEST RESULTS
0-6 Code Dump Mode (if selected after test 7)
7 Configuration Printout
8 Prints one full page in a floating pattern.
9 Continuously sends data to itself (loop back test)
and monitors the received data for any errors. Prints
"LOOP TEST PASSED" or "LOOP TEST FAILED"
at approximately ten second intervals. (SEE
CAUTION BEFORE RUNNING DIAGNOSTIC 9.)
Table 8 Twinax Diagnostic Tests
Twinax Operation
Dialing the diagnostic test number into the
“ADDRESS” switch selects the diagnostic
routines. Powering up the printer executes
them. (See NOTE).
You may change the "ADDRESS" switch
while the diagnostic is running (printing) to
step to another diagnostic. (See Table 8 )
caution
Make sure the host twinax cable is not
attached to the "Smart T" twinax auto-
termination cable, while running
diagnostic 9. This will result in system
errors and possibly cause a proc-check
on your system.
note
The "Smart T" supplied with the MPI feature
must be attached to the MPI for all twinax
diagnostics. Remember, it must not be
attached to the host System when running
diagnostic 9.
