Figure 34. Installing the control panel bottom screws
10. Turn the system right side up on the ESD surface.
11. Replace the fan cover.
a) Ensure that the two levers are open.
b) Put the fan cover in place.
c) Rotate the two levers on each side of the fan cover down and in to secure the cover to the system.
Figure 35. Replacing the fan cover
12. Replace the system in the rack and replace the components that you removed.
For instructions, see “Placing a 7063-CR2 system into the operating position” on page 103.
32
Power Systems: Servicing the IBM Power Systems HMC (7063-CR2)
