Server replaceable units
Notes:
1. Field replaceable units (FRUs) must be serviced only by trained service
technicians.
2. Customer replaceable units (CRUs) can be replaced by the customer. Tier 1
CRUs and Tier 2 CRUs are described in the IBM “Statement of Limited
Warranty” (at “Part 3 - Warranty Information”), which is in the Warranty and
Support Information document on the IBM xSeries Documentation CD.
Table 3. Parts listing, Type 8863
Index Description
CRU No.
(Tier 1)
CRU No.
(Tier 2) FRU No.
1 Top cover (all models) 26K8947
2 Power supply, 1300 W (all models) 24R2723
3 Power supply structure (all models) 26K8950
4 Power backplane (all models) 41Y3151
5 PCI-X board assembly (all models) 41Y3155
6 PCI-X switch card assembly (all models) 39M2699
7 Chassis assembly (all models) 26K8946
8 Fan (92 mm) (all models) 39M2694
9 Carrier, LP/media (all models) 39M2521
10 CD drive, 8/24X (primary) (all models) 26K5413
10 CD drive, 8/24X (alternate) (all models) 39M3541
10 CD drive, 8/24X (alternate) (all models) 26K5397
10 CD drive, 8/24X (alternate) (all models) 39M3563
10 CD-RW/DVD drive, 8/24X (alternate) (all models) 26K5407
10 CD-RW/DVD drive, 8/24X (alternate) (all models) 26K5409
10 CD drive, 24X (optional) 26K5415
10 CD drive, 24X (optional) 26K5427
10 CD drive, 127MM (optional) 26K5421
10 CD drive, 127MM (optional) 39M3529
10 CD-RW drive, 14X (optional) 39M3503
11 Microprocessor VRM, 10.2 (optional) 39Y7256
11 Microprocessor VRM, 2U/105A (optional) 24R2750
12 Microprocessor tray (all models) 41Y3157
13 Front bezel (all models) 26K8956
14 Microprocessor, 3.3 GHZ (model 1RX) 13M7878
14 Microprocessor, 3.6 GHZ (model 2RX) 13M7879
14 Microprocessor, 2.67 GHZ (model 3RX) 25R7846
14 Microprocessor, 3.0 GHZ (model 4RX) 25R7847
15 Heat sink (all models) 26K8805
16 Microprocessor baffle (all models) 26K9020
17 Hard disk drive filler (all models) 26K8680
94 IBM xSeries 366 Type 8863: Problem Determination and Service Guide
