3.5-In. Hard Disk Drive Jumper Settings
The configuration of the following jumpers controls the drive’s mode of
operation:
• SP – Slave Present
• DS – Drive Select
• CS – Cable Select
• PK – Park, used as a place to store a jumper
Quantum Fireball TM and ST Series Hard Disk Drives
Table 5-10 Quantum Fireball TM and ST Series Hard Disk Drives Jumper
Settings
DS CS SP Description
On Off --
Drive configured as a Master, or
Drive configured as a Master, with an attached Slave
Off Off -- Drive configured as a Slave.
Seagate Hard Disk Drive
Table 5-11 Seagate Hard Disk Drive Jumper Settings
DS CS/SP Description
On Off Drive configured as a Master.
Off Off Drive configured as a Slave.
On On Drive configured as a Master, with an attached Slave
Maxtor Hard Disk Drive
Table 5-12 Maxtor Hard Disk Drive Jumper Settings
J50:Master/Slave Description
On
Drive configured as a Master, or
Drive configured as a Master, with an attached Slave
Off Drive configured as a Slave.
