• 1 and 2 Length of tailgate opening
• 3 Width of tailgate opening
Figure 9. DS8900F top exit bracket feature
Physical footprint
The physical footprint dimensions, caster locations, and cable openings of the storage system help you
plan your installation site.
The following gure shows the overall physical footprint of a storage system. The following dimensions
are labeled on Figure 10 on page 89
1 Front service clearance
2 Depth of frame without covers
3 Width of frame without covers
4 Minimum dimension between casters and outside edges of frames
5 Leveling pads
6 Back service clearance
7 Leveling pads
88
IBM DS8900F: DS8900F Introduction and Planning Guide
