Table 46. Three-phase input voltages and frequencies
Characteristic Three-phase delta (3ØΔ) Three-phase wye (3ØY: LL[Line-to-
Line])
Nominal input voltages 200, 208 RMS V AC 380, 400, or 415 RMS V AC
Minimum tolerated input
voltage
180 RMS V AC 315 RMS V AC
Maximum tolerated input
voltage
256 RMS V AC 456 RMS V AC
System maximum current
rating
48 Amps (per PDU cord) 32 Amps (per PDU cord)
Wall breaker rating (3 ph)
1
60 - 63 Amps 30 - 32 Amps20 - 32 Amps
Steady-state input
frequencies
50 ± 3 or 60 ± 3.0 Hz 50 ± 3 or 60 ± 3.0 Hz
PLD input frequencies (<10
seconds)
50 ± 3 or 60 ± 3.0 Hz 50 ± 3 or 60 ± 3.0 Hz
1. Regions such as the United States and Canada require 20% derating for power distribution circuits.
Verication of applicable local standards is required for system installation. Some conguration
restrictions to limit power consumption can allow reduced breaker ratings on a regional basis.
Power connector requirements
Ensure that the site where you plan to install the storage system meets the power connector
requirements.
Table 47 on page 96 shows the power cords and the inline connectors and receptacle types that they
support. Find the power cord row that is appropriate for your site. Ensure that your site meets the
specied power connector requirements.
Attention:
• For reliable operation do not use Ground Fault Circuit Interrupter (GFCI), Earth Leakage Circuit
Breaker (ELCB), or Residual Current Circuit Breaker (RCCB) type circuit breakers with the
DS8900F. The DS8900F is certied for safe operation and compliant with IEC, EN, UL, and CSA
60950-1 standards. If local electrical practice requires leakage detection circuit breakers, they
must be rated at minimum to 300 mA or larger to reduce the risk of outage due to spurious
actuation.
• Do not exceed the wire rating of the facility and ensure that separate protected branch circuits
are used for each cord in planning for redundancy.
Table 47. DS8900F power cords
Power cord feature
code
Power cord description
6
Inline connector/
Receptacle
Wire gauge
1038 Single-phase power cord, 208 V, 30
A, NEMA L6-30P
NEMA L6-30P/NEMA
L6-30R
10 AWG
1039 Single-phase power cord, 250 V, 32
A, IEC-309
332P6W/332R6W 10 AWG
1040 Three-phase power cord, 250 V, 60
A, IEC-309 (four-pin Delta)
460P9W/460R9W 6 AWG
1041 Three-phase power cord, 250 V, 32
A, IEC-309 (ve-pin Wye)
532P6W/532R6W 10 AWG
96 IBM DS8900F: DS8900F Introduction and Planning Guide
