IBM FlashSystem 5000 Series User Manual

Figure 8. Opening the hinge brackets
6. Align the holes in the rail bracket with the holes on the front and rear rack cabinet flanges.
Ensure that the rails are aligned on the inside of the rack cabinet.
7. On the rear of the rail, press the two bracket pins into the holes in the rack flanges.
8. Close the rear hinge bracket to secure the rail to the rack cabinet flange.
(See Figure 9 on page 24.)
Figure 9. Closing the hinge brackets
9. On the front of the rail, press the two bracket pins into the holes in the rack flanges.
10. Close the front hinge bracket to secure the rail to the rack cabinet flange.
Figure 9 on page 24 shows an example.
24
IBM FlashSystem 5000 : FlashSystem 5000 Quick Installation Guide

IBM FlashSystem 5000 Series Specifications

General

Model	IBM FlashSystem 5000 Series
Storage Type	Flash
Management Software	IBM Spectrum Virtualize
Form Factor	2U
Drive Types	SAS
RAID Support	RAID 5, RAID 6
Host Interface	16 Gbps Fibre Channel, 25 Gbps iSCSI, 12 Gbps SAS
Data Reduction	Yes (compression, deduplication)
Encryption	Yes
Replication	Yes, Metro Mirror, Global Mirror
Operating System Support	Windows, Linux, AIX, IBM i
Cache	64GB
