Chapter 2: Hardware Installation 25
The diagram below illustrates the part of the nut clip that must be on the
inner side of the flange after the nut clip is clamped sideways onto the
flange.
2 The nut clips to be clamped sideways
onto the flanges of the rack
3 The rear portion of the rack
4 The front portion of the rack
Label Description
