System component Description
FCIP (IP over Fibre
Channel)
Complies with FC-IP 2.3 of FCA prole
Port Status Bicolor LED (amber/green) for SFP+ ports. Tricolor LED (white/amber/green) for DD
ports.
Other
System component Description
Serial console port One three-wire (Tx, Rx, GND) UART RJ-45 serial port.
Ethernet management
port
One 1000/100/10 Mbps Ethernet port
USB port One external USB port
LEDs
System component Description
System power LED One green system power status LED (lower) on the port side.
System status LED One bicolor (green/amber) system status LED (upper) on the port side.
Ethernet port link LED One green link LED to the left of the RJ-45 connector on the port side.
Ethernet port activity LED One activity LED to the right of the RJ45 connector on the port side.
Serial console port LED The serial console port LEDs on the port side remain off at all times, even when a
cable is inserted and the link is active.
FC port status LED 112 port status LEDs on the port side of the switch: 96 bicolor (green/amber)
LEDs, one for each SFP+ port, and 16 tricolor (white/amber/green) LEDs, one for
each DD port.
Power supply status LEDs One green OK status LED on each power supply assembly on the nonport-side of
the switch.
One amber FAIL status LED on each power supply assembly on the nonport-side of
the switch.
Fan assembly status LED One bicolor fan assembly status LED on each fan assembly on the nonport-side of
the switch.
Other
System component
Description
Serial cable RJ-45 console cable
RJ-45 to DB9 adapter RJ-45 to DB9 for console cable
76 IBM Storage Networking SAN128B-7: SAN128B-7 Installation, Service, and User Guide
