Appendix A. Product specications
This topic highlights the features and specications for the SAN128B-7 switch.
System specications
System component Description
Enclosure 2U, power from back
• Front-to-back airflow/nonport-side exhaust
• Back-to-front airflow/nonport-side intake
Power inlet C14
Power supplies Dual, hot-swappable redundant power supplies with integral cooling fans and
status LEDs.
Fans Three hot-swappable redundant fan assembly units with system cooling fans and
status LEDs.
Cooling Port side to the nonport-side of the switch (nonport-side exhaust) and nonport-
side to the port side (port-side exhaust)
System architecture Nonblocking shared memory switch
System processors Freescale T1042E CPU
Port-to-port latency <900 nanoseconds (including FEC) with no contention (destination port is free)
Fibre Channel
System component
Description
Fibre Channel ports 9
96 SFP+ ports that support any combination of short wavelength (SWL) and long
wavelength (LWL) or extended long wavelength (ELWL) optical media. 16 DD ports
that support 64G SFP-DD or SFP+ transceivers. The SFP+ ports are capable of
autonegotiating to 8, 10, 16, 32, or 64G speeds depending on the SFP+ model and
the minimum supported speed of the optical transceiver at the other end of the
link.
• A 64G optical transceiver can autonegotiate to 64G, 32G, or 16G.
• A 32G optical transceiver can autonegotiate to 32G, 16G, or 8G.
• A 10G optical transceiver can autonegotiate to 10G.
ANSI Fibre Channel
protocol
FC-PH (Fibre Channel Physical and Signaling Interface standard) with NVMe
support
Modes of operation Fibre Channel Class 2 and Class 3
Fabric initialization Complies with FC-SW-3 Rev. 6.6
©
